Plywood Glue Spreader

Plywood Glue Spreader
Plywood Glue Spreader
Product Code : PGS 05
Product Description

Loaded with immense industrial experience, we have positioned ourselves as a superior manufacturer, exporter and supplier of wide gamut of Plywood Glue Spreader to our prestigious clients. The offered machine is widely used for spreading the glue on both side of veneer in the veneer peeling line. The provided machine is manufactured by our diligent professionals by making use of supreme grade components and latest techniques as per the defined industry trends. Apart from this, our offered Plywood Glue Spreader is rigorously tested on different measure to meet the set benchmark of quality.


  • Rugged design
  • High operational fluency
  • Unmatched performance
  • Low maintenance

Range Of Application:

  • Plywood machine glue spreader, this machine spread glue on the veneer two side.
  • Good machine spread glue the same amd save more glue.
  • It can also ues other field.
Plywood machine glue spreader parameter:
Diameter of glueing roller    ÃŽ¦430mm
Diameter of gule extruding roller       ÃŽ¦292mm
Length of rollers    2700mm
Speed ratio of glueing roller and glue extruding roller  8.9:1
Input height  1000mm
Input speed Fast 76m/min or 49m/min
Input speed   Slow  50m/min or 33m/min
Thickness  17.5mm
Rigidity 55℃
Maximum space of glueing roller   50mm
Inside height and depth of output roller 752x1623mm
Overall size 4080x2920x1530mm
Weight     4500kg
